NSN 4820-00-122-1160
Part Details | PLUG VALVE
4820-00-122-1160 A valve designed to control the flow of a fluid by the rotation of a ported plug or plug sector within a suitable ported seat. The plug requires lubrication for ease of operation or contains a bonded composition seal(s). See also VALVE, SEATLESS and COCK, PLUG.
Alternate Parts: 4233304, 4233304, 4820-00-122-1160, 00-122-1160, 4820001221160, 001221160
| Supply Group (FSG) | NSN Assigned | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | JAN 01, 1963 | 00-122-1160 | 05490 ( VALVE, PLUG ) |
REFERENCE DRAWINGS & PICTURES
TWO-WAY THREE PORT BOTTOM OUTLET 90 DEGREE PLUG TURN
Cross Reference | NSN 4820-00-122-1160
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 4233304 | 88277 | BOEING COMPANY, THEDBA BOEING |
| 4233304 | 18355 | BOEING COMPANY, THEDBA BOEING |
Technical Data | NSN 4820-00-122-1160
| Characteristic | Specifications |
|---|---|
| FLOW STYLE | TWO-WAY THREE PORT BOTTOM OUTLET 90 DEGREE PLUG TURN |
| VALVE OPERATION METHOD | MANUAL |
