NSN 4140-01-521-1350
Part Details | TUBEAXIAL FAN
4140-01-521-1350 A nonpositive displacement mechanical device without guide vanes and having an axial fan impeller inclosed within a tubular housing. It is designed primarily for duct installation to move air or gas axially over a wide range of volumes at medium pressures.
Alternate Parts: OS7000FTTC, OS7000-FTTC, 90228440, 902284-40, 0S7000FT, 0S7000-FT, OS9000FTTC, OS9000-FTTC, OS7700FT001, OS7700-FT-001, 4140-01-521-1350, 01-521-1350, 4140015211350, 015211350
| Supply Group (FSG) | NSN Assigned | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 41 | JUN 10, 2004 | 01-521-1350 | 04244 ( FAN, TUBEAXIAL ) |
REFERENCE DRAWINGS & PICTURES
PORTABLE NONADJUSTABLE
Cross Reference | NSN 4140-01-521-1350
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| OS7000-FTTC | 0Z321 | ALCATEL INTERNETWORKING INC. |
| 902284-40 | 0Z321 | ALCATEL INTERNETWORKING INC. |
| 0S7000-FT | 0Z321 | ALCATEL INTERNETWORKING INC. |
| OS9000-FTTC | 0Z321 | ALCATEL INTERNETWORKING INC. |
| OS7700-FT-001 | 29355 | NAVY, UNITED STATES DEPARTMENT OFTHE |
Technical Data | NSN 4140-01-521-1350
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | A PORTABLE NONADJUSTABLE |
| ROTATION DIRECTION FOR WHICH DESIGNED | CLOCKWISE |
| PRIME MOVER TYPE | ELECTRIC MOTOR |
| PRIME MOVER POWER RATING | 80.0 WATTS |
| SPECIAL FEATURES | THE FAN TRAY CONSISTS OF 3 INDEPENDENTLY-OPERATING FANS AND IS THE MAIN TEMPERATURE CONTROL COMPONENT OF THE SWITCH. THE FAN TRAY PROVIDES COOLING AIRFLOW FOR ALL NI MODULES & CMM'S. THIS AIRFLOW IS A CRUCIAL FACTOR IN THE SWITCH'S OVERALL OPERABILITY. THE FAN TRAY HAS AN ONBOARD CONNECTOR THAT PLUGS INTO A POWER CONNECTOR SOCKET ON THE CHASSIS |
| END ITEM IDENTIFICATION | OMNISWITCH 7700 |
